Forged Erection Anchors Price:¥

This product is ideal for hoisting and transferring thin-walled concrete components from horizontal to vertical, this anchor safely transfers all applied loads to the concrete, helping prevent damage or cracking. The shear bar is required with this anchor. A tension bar is typically needed to achieve higher load capacities. Available in 2 T, 4 T, and 8 T capacities, with a hot-dipped galvanized finish for corrosion resistance. Impact-resistant, performing reliably even in freezing temperatures.

Online inquiry
Detailed content Specification parameter Product packaging




This product is ideal for hoisting and transferring thin-walled concrete components from horizontal to vertical, this anchor safely transfers all applied loads to the concrete, helping prevent damage or cracking. The shear bar is required with this anchor. A tension bar is typically needed to achieve higher load capacities. Available in 2 T, 4 T, and 8 T capacities, with a hot-dipped galvanized finish for corrosion resistance. Impact-resistant, performing reliably even in freezing temperatures.


板19-3D-logo底纹压缩Forged Erection灰底1.1.png



Ton

Item ID

Ring Clutch System

L

D

W

3T

MAP-SFEA-3

 2T-3T

8”

3/8”

 2-3/8”

6T

MAP-SFEA-6

4T-6T

 10-1/2”

5/8”

3-3/16”

12T

MAP-SFEA-12

8T-12T

12-1/2”

 3/4”

 3-3/4”
