STRAIGHT LOOP COIL Price:¥

The Straight Loop Ferrule Insert is typically used to attach a precast wall panel to a building frame, as well as to provide attachment of other structural elements that may be required. Available in 1/2”, 5/8”, 3/4” and 1” sizes. Standard finish is plated.

Online inquiry
Detailed content Specification parameter Product packaging

The Straight Loop Ferrule Insert is typically used to attach a precast wall panel to a building frame, as well as to provide attachment of other structural elements that may be required. Available in 1/2”, 5/8”, 3/4” and 1” sizes. Standard finish is plated.


 1-3D底纹压缩-STRAIGHT LOOP COIL.png

Item ID

Size

L

W

D

Insert Ultimate Mechanical Load Tension (LBS)

ZLZZ-FLI3840

3/8"-16-UNC

2-3/4”

1-1/2”

14/25”

≥9000

ZLZZ-FLI1240

1/2"-13-UNC

2-3/4”

1-5/8”

9/16”

≥9000

ZLZZ-FLI5840

5/8"-11-UNC

3-1/2”

2-1/8”

13/16”

≥9000

ZLZZ-FLI3466

3/4"-10-UNC

3-1/2”

2-1/4”

13/16”

≥15000

ZLZZ-FLI7880

7/8"-9-UNC

6”

3-3/8”

2”

≥18000

ZLZZ-FLI1080

1"-8-UNC

6”

3-3/8”

2-1/8”

≥18000
