The Thin Slab Ferrule Insert is designed for use where the depth of embedment is limited and where limited capacity is required in tension. Available in 1/4”, 1/2”, 5/8” and 3/4” sizes. Standard finish is plated.
Item ID
Size
L
H
D
Tension (LBS)
ZLZZ-TSF-146
1/4"-20-UNC
4”
1-1/4”
0.256”
≥450
ZLZZ-TSF-1212
1/2"-13-UNC
1-3/8”
≥900
ZLZZ-TSF-5813
5/8"-11-UNC
1-5/8”
≥1000
ZLZZ-TSF-3421
3/4"-10-UNC
≥1600
