The U-Anchor Recess Member is specially designed for U-Anchors and typically used in retaining wall blocks. The Recess Members are
bolted to the form using (2) 1/2” coil threaded holding rods [QL131] or (2) 1/2”x 2” coil bolts [CB14H122]. If using the coil bolt, user must be
careful not to over torque the bolt as it will strip the coil nut out of the recess member.
Part # AnchorSize Color L H W Weight (lbs)
ZLZZ-U-38 3/8” Green 6-3/16” 3-1/8” 4-3/4” 2.06
ZLZZ-U-716 7/16” Red 6-3/16” 3-1/8” 4-3/4” 2.16
