Spherical Head Lifting Anchor

The T-bar system is a quick-connection lifting system with lifting load ranging from 1.3 to 32 tons. The system structure includes T-bar, spreader and rubber mold, which is used to lift precast concrete beams, thick floors, wallboards and concrete pipes.

Online inquiry

Previous Next

Detailed content Specification parameter Product packaging

1-3d底纹压缩-Spherical Head Lifting Anchor.png

Item	Item No	Size	L	D
1	ZLZZ-SHLA-1.3T-35	1.3T	1-1/3”	2/5”
2	ZLZZ-SHLA-1.3T-45	1.3T	1-3/4”	2/5”
3	ZLZZ-SHLA-1.3T-50	1.3T	1-19/20”	2/5”
4	ZLZZ-SHLA-1.3T-55	1.3T	2-1/6”	2/5”
5	ZLZZ-SHLA-1.3T-60	1.3T	2-1/3”	2/5”
6	ZLZZ-SHLA-1.3T-65	1.3T	2-1/2”	2/5”
7	ZLZZ-SHLA-1.3T-85	1.3T	3-1/3”	2/5”
8	ZLZZ-SHLA-1.3T-120	1.3T	4-3/4”	2/5”
9	ZLZZ-SHLA-1.3T-240	1.3T	9-1/2”	2/5”
10	ZLZZ-SHLA-2.5T-55	2.5T	2-1/6”	1/2”
11	ZLZZ-SHLA-2.5T-65	2.5T	2-1/2”	1/2”
12	ZLZZ-SHLA-2.5T-70	2.5T	2-3/4”	1/2”
13	ZLZZ-SHLA-2.5T-75	2.5T	2-19/20”	1/2”
14	ZLZZ-SHLA-2.5T-85	2.5T	3-1/3”	1/2”
15	ZLZZ-SHLA-2.5T-90	2.5T	3-1/2”	1/2”
16	ZLZZ-SHLA-2.5T-120	2.5T	4-3/4”	1/2”
17	ZLZZ-SHLA-2.5T-140	2.5T	5-1/2”	1/2”
18	ZLZZ-SHLA-2.5T-170	2.5T	6-2/3”	1/2”
19	ZLZZ-SHLA-2.5T-210	2.5T	8-1/4”	1/2”
20	ZLZZ-SHLA-2.5T-240	2.5T	9-1/2”	1/2”
21	ZLZZ-SHLA-2.5T-280	2.5T	11”	1/2”
22	ZLZZ-SHLA-5T-65	5T	2-1/2”	4/5”
23	ZLZZ-SHLA-5T-75	5T	2-19/20”	4/5”
24	ZLZZ-SHLA-5T-85	5T	2-1/2”	4/5”

Item	Item No	Size	L	D
25	ZLZZ-SHLA-5T-90	5T	3-1/2”	4/5”
26	ZLZZ-SHLA-5T-95	5T	3-3/4”	4/5”
27	ZLZZ-SHLA-5T-110	5T	4-1/3”	4/5”
28	ZLZZ-SHLA-5T-120	5T	4-3/4”	4/5”
29	ZLZZ-SHLA-5T-140	5T	5-1/2”	4/5”
30	ZLZZ-SHLA-5T-170	5T	6-2/3”	4/5”
31	ZLZZ-SHLA-5T-180	5T	7”	4/5”
32	ZLZZ-SHLA-5T-240	5T	9-1/2”	4/5”
33	ZLZZ-SHLA-5Τ-480	5Τ	18-8/9”	4/5”
34	ZLZZ-SHLA-10T-115	10T	4-1/2”	1-1/10”
35	ZLZZ-SHLA-10T-120	10T	4-3/4”	1-1/10”
36	ZLZZ-SHLA-10T-135	10T	5-1/3”	1-1/10”
37	ZLZZ-SHLA-10T-150	10T	5-8/9”	1-1/10”
38	ZLZZ-SHLA-10T-170	10T	6-2/3”	1-1/10”
39	ZLZZ-SHLA-10T-180	10T	7”	1-1/10”
40	ZLZZ-SHLA-10T-220	10T	8-5/8”	1-1/10”
41	ZLZZ-SHLA-10T-200	10T	7-7/8”	1-1/10”
42	ZLZZ-SHLA-10T-250	10T	9-7/8”	1-1/10”
43	ZLZZ-SHLA-10T-340	10T	13-1/3”	1-1/10”
44	ZLZZ-SHLA-10T-680	10T	26-3/4”	1-1/10”
45	ZLZZ-SHLA-20T-200	20T	7-7/8”	1-1/2”
46	ZLZZ-SHLA-20T-250	20T	9-7/8”	1-1/2”
47	ZLZZ-SHLA-20T-500	20T	19-5/8”	1-1/2”
48	ZLZZ-SHLA-32T-700	32T	27-1/2”	1-11/12”
