The R-Anchor System is specially designed to be used in both recessed applications for retaining wall blocks and protruding from the concrete for small slabs. Standard finish is hot-dipped galvanized.
Item ID
Ultimate Tensile
Requirement (LBS)
D
L
W
ZLZZ-RAN-83
≥6,400
1/4”
6”
2-11/16”
ZLZZ-RAN-133
≥12,800
5/16”
6-1/2”
2-5/8”
ZLZZ-RAN-133EX
≥18,760
3/8”
7”
2-3/4”
ZLZZ-RAN-28
≥30,000
7/16”
9”
3-1/2”
ZLZZ-RAN-201
11”
